Graphite packing with PTFE corners

Graphite packing with PTFE corners

Item:CAZ-P240
PDF:14-240P,P240 Improved Graphite.pdf>

Specification:

Description:PTFE corners effectively prevent graphite extrusion, this packing contains the advantage of PTFE and graphite. Graphited PTFE corner CAZ-G240 is also efficient.

APPLICATIONG:

Can be used in many demanding applications, both dynamic and static. Particularly suited for high temperature and high pressure service in valves, pumps, expansion joints, mixers and agitators of pulp and paper, power station and chemical plant etc.

PARAMETER:

Temperature
+280ˇăC
Pressure-Speed
Rotating
25bar-20m/s
Reciprocating
100bar-20m/s
Valve
300 bar-20m/s
PH range
0~14
Density
1.3~1.5g/cm3

PACKAGING:

in coils of 5 or 10 kg, other package on request.
as packing rings--- RP240
as precut length
