Super-high Temperature & Pressure Valve Packing

Super-high Temperature & Pressure Valve Packing

Item:CAZ-240M
PDF:15-240M,C240E Graphite.pdf>

Specification:

Description:Braided from low-sulphur expanded graphite yarns with corrosion inhibitor, reinforced with Inconel wire. Each yarn is round braided with Inconel mesh again. The exclusive packing is formable, yet tough. Rated in steam service 550bar, maintains integrity in steam up to 850ˇăC. It is a cost-effective as well as a confident choice.

CONSTRUCTION:

240AM Graphite Packing Wrapped with Aramid Mesh
GramidTM-- Each yarn is wrapped with Aramid filament. The high strength Aramid mesh make the packing 3 times more resistant to extrusion and also increase the pressure handing capabilities. Similar to Garlock 1304.

PARAMETER:

Pressure
500Bar
Speed
2m/s
PH
0~14
Density
1.1~1.4g/cm3
Temperature
-220~+550ˇăC (+650ˇăC steam)

PACKAGING:

in coils of 5 or 10 kg
as packing rings R240M,R240AM;
as pre-cut length
